Self Modifying Code
What is self modifying code.
It is like the name itself suggests, code which as part of what it is designed to do when you run it, modifies itself.
It is basically a relic of the past, except perhaps in kernel development, or on embedded systems, and even then the costs almost certainly outweigh the benefits in most cases.
A REALLY bad high level example.
This isn’t self modifying code, but it gives you the jist of the idea in a high level language.
This is Python that uses the operator standard library functions in order to swap in an operator based on changes in the state of the program.
This program will count up from 0 to 10, then count back down to 0 again and repeat this ad infinitum.
import operator
import time
op = operator.add
i = 0
while True:
print(i)
time.sleep(0.2)
i = op(i, 1)
if i >= 10:
op = operator.sub
if i <= 0:
op = operator.add
A C example using function pointers.
This does the same thing in C, but it uses function pointers to swap between the increment and decrement functions.
#include <stdio.h>
#include <unistd.h>
int i = 0;
int increment(int x) {
return x + 1;
}
int decrement(int x) {
return x - 1;
}
int main(int argc, char **argv) {
/* Make a function pointer, starting out pointing at increment */
int (*op)(int);
op = increment;
while (1) {
printf("%d\n", i);
usleep(200 * 1000);
i = op(i);
if (i >= 10) {
op = decrement;
}
if (i <= 0) {
op = increment;
}
}
}
Because we wrote this in C, we can prove that it is indeed not self modifying either by examining the assembly produced
while compiling it. This however is quite complex, even for a trivial example like this. Compiling this program to assembly with
$ gcc -O0 -S -o no_self_mod.asm no_self_mod.c produces over 100 lines of AMD64 assembly. Expand the section below to view
this assembly if you care.
the AMD64 assembly for the C program above
.file "no_self_mod.c"
.text
.globl i
.bss
.align 4
.type i, @object
.size i, 4
i:
.zero 4
.text
.globl increment
.type increment, @function
increment:
.LFB0:
.cfi_startproc
endbr64
pushq %rbp
.cfi_def_cfa_offset 16
.cfi_offset 6, -16
movq %rsp, %rbp
.cfi_def_cfa_register 6
movl %edi, -4(%rbp)
movl -4(%rbp), %eax
addl $1, %eax
popq %rbp
.cfi_def_cfa 7, 8
ret
.cfi_endproc
.LFE0:
.size increment, .-increment
.globl decrement
.type decrement, @function
decrement:
.LFB1:
.cfi_startproc
endbr64
pushq %rbp
.cfi_def_cfa_offset 16
.cfi_offset 6, -16
movq %rsp, %rbp
.cfi_def_cfa_register 6
movl %edi, -4(%rbp)
movl -4(%rbp), %eax
subl $1, %eax
popq %rbp
.cfi_def_cfa 7, 8
ret
.cfi_endproc
.LFE1:
.size decrement, .-decrement
.section .rodata
.LC0:
.string "%d\n"
.text
.globl main
.type main, @function
main:
.LFB2:
.cfi_startproc
endbr64
pushq %rbp
.cfi_def_cfa_offset 16
.cfi_offset 6, -16
movq %rsp, %rbp
.cfi_def_cfa_register 6
subq $32, %rsp
movl %edi, -20(%rbp)
movq %rsi, -32(%rbp)
leaq increment(%rip), %rax
movq %rax, -8(%rbp)
.L8:
movl i(%rip), %eax
movl %eax, %esi
leaq .LC0(%rip), %rax
movq %rax, %rdi
movl $0, %eax
call printf@PLT
movl $200000, %edi
call usleep@PLT
movl i(%rip), %eax
movq -8(%rbp), %rdx
movl %eax, %edi
call *%rdx
movl %eax, i(%rip)
movl i(%rip), %eax
cmpl $9, %eax
jle .L6
leaq decrement(%rip), %rax
movq %rax, -8(%rbp)
.L6:
movl i(%rip), %eax
testl %eax, %eax
jg .L8
leaq increment(%rip), %rax
movq %rax, -8(%rbp)
jmp .L8
.cfi_endproc
.LFE2:
.size main, .-main
.ident "GCC"
.section .note.GNU-stack,"",@progbits
.section .note.gnu.property,"a"
.align 8
.long 1f - 0f
.long 4f - 1f
.long 5
0:
.string "GNU"
1:
.align 8
.long 0xc0000002
.long 3f - 2f
2:
.long 0x3
3:
.align 8
4:
Problems with self modifying code.
I’m going to do a demo of self modifying code in a moment, but first I’m going to explain why I’m not doing it in a modern OS and a modern set of tools, with a modern dialect of assembly like x64 or ARM64.
There are many reasons that self modifying code is considered harmful and or dangerous.
-
It is REALLY hard to understand. Much more if you don’t expect it. Even more if you have no idea of the concept. This is most certiainly the type of dirty programming technique you need to write comments around !
-
Modern operating systems make it hard to use. Tools such as Microsoft Windows arbitary code guard, or Linux with W^X, (Write XOR Execute, also sometimes called XD, DX, for Execute Bit Disable) are designed to prevent security problems by literally preventing self modifying code.
The Linux kernel itself makes extensive use of self modification, as shown in Evgeniy Paltsev’s presentation to the embedded linux conference in 2019, you still shouldn’t use this in the old school way of modifying code you are actually executing.
And Old School Example.
This very old example uses an ancient CPU and dialect of assembly, as this is where I first learned this technique, and honestly it is the only place I have ever actually used it.
This uses the Masswerk 6502 simulator to create and step through a program designed to do the same thing as the previous examples, but to do so in a real self modifying way.
LDX #$00 ; Load 0 into the X register
mainloop:
NOP ; Do nothing, imagine this is the "print"
INX ; Increment X, this code ends up at location 0x0003.
CPX #$0A ; Compare X with 10.
BEQ setdec ; Jump to self mod if 10.
CPX #$00 ; Compare X with 0.
BEQ setinc ; Jump to self mod if 0.
JMP mainloop ; Go around loop again.
setinc:
LDY #$E8 ; Put the bits for the INX instruction in the Y register.
STY $0003 ; Store this in the INX location in the main code, the third line.
JMP mainloop ; Jump back to main code.
setdec:
LDY #$CA ; Put the bits for the DEX instruction in the Y register
STY $0003 ; Store this in the INX location in the main code, the third line.
JMP mainloop ; Jump back to main code
To experiment with this yourself.
- Go to the masswerk emulator
- Paste in this assembly above into the “src” section.
- Click “Assemble”.
- Click “Show in Emulator”.
- Paste the object code into the RAM section, with “Strip Leading Addresses” ticked.
- Click “Load Memory”.
- Click “Show Memory”.
- Click “Live Update” for memory.
- Tick “Trace” so you can watch each instruction as it is executed.
- Click “Continuous Run”.
Now you will be able to watch the value of the XR register climb up from 0 to 10 (A) and back again
over and over, just like the previous examples and it is doing so using self modifying code.
You can watch the self modifying code working by looking at the first line of the memory. It toggles between these two states.
GOING UP:
0000: A2 00 EA E8 E0 0A F0 0F
GOING DOWN:
0000: A2 00 EA CA E0 0A F0 0F`
The E8 instruction in 6502 assembler is INX, and the CA instruction is DEX.
The two “functions”, setinc and setdec both add an one of these opcodes to the Y register, and then store this in the program code itself directly (at location 0003).
This is still a bit of a contrived example, but it gives the jist of the idea. Back in the 8bit and 16bit days, these techniques were used to optimise code, particularly in games.
You will find plenty of cases of them in 6502 code,
Takeaways
Self modifying code is mostly a relic of the past, except in kernel development, or on embedded systems. These are certainly not things I do much of day to day or have much experience with.
However, if you did need a brief introduction to the concept of self modifying code, I hope this blog post helped.
